HTI Mini Outdoor Thermal Night Vision Telescope Monocular Scope With Imaging Camera, HT-A4

Price 109940.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

HTI Mini Outdoor Thermal Night Vision Telescope Monocular Scope With Imaging Camera, HT-A4 Specification

Connectivity Type
USB Type-C (for charging and data transfer)

Camera Range
Detection range up to 180 meters

Camera Type
Handheld monocular

Sensor Type
Infrared thermal sensor

Camera Style
Monocular scope

Technology
Thermal imaging

Special Features
Mini outdoor thermal night vision, built-in imaging camera, compact and lightweight design, high sensitivity detector, quick startup, supports photo and video recording

Application
Outdoor observation, hunting, wildlife surveillance, patrolling, and search and rescue

Camera Size
About 53mm x 25mm x 140mm

Camera Pixels
384 x 288 pixels

Screen Resolution
720 x 540 pixels

Image/Video Quality
High-quality thermal imaging; photo and video recording

Power Supply
Built-in rechargeable lithium battery (5V/2A); up to 8 hours working time

Output Formats
JPG (photo), MP4 (video)

File Compatibility
Supports standard microSD cards

Protection Level
IP66 water and dust resistant

Focal Length
13mm

Viewing Mode
Multiple color palettes (White-hot/Black-hot/Color)

Operating Temperature Range
-20C to +50C

Display Type
LCOS display

Spectral Range
8~14 m

Optical Magnification
1x digital zoom

Storage Capacity
Supports up to 32GB microSD card

Mounting
Handheld (strap included)

Startup Time
Less than 5 seconds

Weight
Approximately 210g

Frame Frequency
25Hz

HTI Mini Outdoor Thermal Night Vision Telescope Monocular Scope With Imaging Camera, HT-A4 Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
2 Days

About HTI Mini Outdoor Thermal Night Vision Telescope Monocular Scope With Imaging Camera, HT-A4

True Sense HT-A4 Thermal Imaging Camera features a large 5-inch external color display for enhanced viewing. Designed for outdoor search and inspection tasks, it delivers clear thermal images with a bright 800480 LCD screen.

Features:

Large 5-inch color display
800480 LCD resolution
External screen thermal camera
Clear and detailed imaging
Handheld ergonomic design
Ideal for outdoor search
Easy-to-read thermal visuals
Portable and durable
Professional inspection tool

Advanced Thermal Imaging Technology

Equipped with a high-resolution thermal sensor (384 x 288 pixels) and a broad spectral range (8-14 m), the HT-A4 delivers sharp, high-quality thermal images and videos. Its technology ensures clear visualization even in complete darkness, fog, or challenging weather, making it ideal for varied outdoor scenarios.

User-Friendly and Versatile Operation

The monocular is easy to operate with quick startup (less than 5 seconds) and supports multiple image palettes for different observation needs. Its handheld design, light weight, and included strap ensure comfort during prolonged use, making it practical for hunters, wildlife watchers, and rescue teams.

Rugged Design and Reliable Performance

With an IP66 rating, the HT-A4 is built to withstand dust and powerful water jets, ensuring reliable performance in harsh environments. The battery provides up to 8 hours of operation, and data transfer or charging is convenient via USB Type-C. Its robust build makes it a trustworthy companion for demanding outdoor activities.

FAQ's of HTI Mini Outdoor Thermal Night Vision Telescope Monocular Scope With Imaging Camera, HT-A4:

Q: How do I record images and videos with the HTI Mini Outdoor Thermal Night Vision Monocular?

A: To record images or videos, simply insert a microSD card (up to 32GB) into the device, select the photo or video mode via the menu, and use the designated button to capture JPEG images or MP4 video footage. The stored files can be accessed and transferred via the USB Type-C port.

Q: What benefits does thermal imaging provide for outdoor observation and search operations?

A: Thermal imaging detects heat signatures, allowing users to see living beings or objects in complete darkness, fog, smoke, or through vegetation. This is advantageous for wildlife spotting, tracking, search and rescue, and security tasks where visibility is compromised.

Q: When is the best time to use the HTI HT-A4 monocular scope?

A: The device is effective both day and night, but its full potential is realized in low-light or night scenarios. It's particularly beneficial during dusk, nighttime, or in environments with heavy fog or dense vegetation where standard night vision falls short.

Q: Where can the HTI HT-A4 be used effectively?

A: It can be used in a wide range of outdoor environments such as forests, wildlife reserves, large open fields, mountainous terrain, or during urban patrolling. Its compact, IP66-certified design ensures it performs reliably in wet, dusty, or rugged locations.

Q: What is the process to recharge the monocular and how long does the battery last?

A: Recharge the HT-A4 using the included USB Type-C cable, connecting it to any compatible power adapter. The built-in lithium battery offers up to 8 hours of operating time on a full charge, making it suitable for extended field use.

Q: Which viewing modes does the device support and how do they enhance observation?

A: The device features multiple color palettes like white-hot, black-hot, and color. Switching between these modes helps users identify targets more distinctly against different backgrounds and provides flexibility according to the observation conditions.

Q: What type of memory card should I use and which file formats are supported?

A: The HTI HT-A4 supports standard microSD cards with up to 32GB capacity. Photos are saved in JPEG format and videos in MP4, which are compatible with most computers and media devices for easy playback and review.
