HTC Sound Level Meter with Data Logger, SL-1352

Name: HTC Sound Level Meter with Data Logger, SL-1352
Brand: True Sense Technologies
Price: 7990.0 INR
Availability: InStock

Price 7990.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Piece

HTC Sound Level Meter with Data Logger, SL-1352 Specification

Sensor Type
Electret Condenser Microphone

Frequency
31.5 Hz to 8 kHz

Equipment Type
Digital Sound Level Meter with Data Logger

Protection
Overload Indication

Resolution
0.1 dB

Capacity
Data Logging Capacity: Up to 47000 records

Connectivity Type
USB Interface

Measurement Range
30 - 130 dB

Humidity %
10% to 80% RH

Diameter
Microphone Diameter: 1/2 inch

Application Media
Sound Level Measurement

Temperature Range
0C to 40C

Material
ABS Plastic

Power Supply
9V Battery

Power Consumption
About 30mA

Accuracy
1.5 dB

Display Type
Large LCD Display

Range
30 to 130 dB

Operating Environment
Indoor/Outdoor

Weight
approx. 260g (including battery)

Memory
Internal memory for data storage

Mounting Options
Tripod mountable

Data Output
RS232/USB

Dimensions
280mm x 80mm x 35mm

Sampling Rate
2 times/second

Standards
IEC 61672 Class 2

Backlight
Yes

Auto Power Off
Yes

Battery Life
up to 30 hours (alkaline battery)

Response Time
Fast (125ms)/Slow (1s) selectable

Calibration
Manual/Acoustic calibrator available

HTC Sound Level Meter with Data Logger, SL-1352 Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
2 Days

About HTC Sound Level Meter with Data Logger, SL-1352

HTC SL-1352 Digital Sound Level Meter measures 30130 dB with multiple frequency weighting options and fast/slow response modes. Equipped with backlit LCD display and auto power-off for convenience.

Features:

Measures 30130 dB sound levels
A & C frequency weighting
Fast and slow response modes
Backlit LCD display
Data hold function
Auto power-off feature
Portable and lightweight design
Accurate for industrial and environmental use
Easy-to-read readings
Reliable handheld meter

Advanced Data Logging for Extended Analysis

With a robust internal memory holding up to 47,000 records, the SL-1352 makes it effortless to track and analyze sound levels over extended sessions. The built-in data logger enables professionals to capture historical noise trends, troubleshoot issues, and ensure regulatory compliance effectively.

User-Friendly Operation and Versatile Design

Equipped with a large backlit LCD, tripod mounting, and automatic power-off functionality, this sound level meter supports simple setup and extended field or laboratory measurements. Its lightweight design (approx. 260g with battery) and durability make it suitable for both indoor and outdoor environments.

Precision and Compliance Assured

Compliant with IEC 61672 Class 2 standards, the SL-1352 offers reliable accuracy (1.5 dB) across a wide measurement range from 30 to 130 dB. Easy calibration options and overload protection ensure long-term, reliable operation in varied acoustic conditions.

FAQ's of HTC Sound Level Meter with Data Logger, SL-1352:

Q: How do I transfer recorded data from the SL-1352 sound level meter to my computer?

A: You can connect the SL-1352 to a computer using its RS232 or USB interface. Once connected, you can download and manage stored data, enabling straightforward analysis and reporting.

Q: What makes the SL-1352 suitable for both indoor and outdoor sound measurement?

A: This model is engineered to work in environments with 10%-80% RH humidity and temperatures from 0C to 40C. Its ABS plastic construction and tripod mount capability further support stability and reliability during indoor and outdoor usage.

Q: When should I calibrate the device for optimal accuracy?

A: It is recommended to calibrate the meter manually using an acoustic calibrator before each measurement session-especially when precise results or regulatory compliance is required.

Q: Where can I mount the SL-1352 for stable operation during measurements?

A: The SL-1352 features a tripod mounting option, which helps provide steady and consistent measurement conditions, especially in environments with variable or fluctuating noise levels.

Q: What is the process for switching between fast and slow response times?

A: You can select between fast (125ms) and slow (1s) response times via the meter's controls, allowing you to capture either rapid sound fluctuations or average readings, depending on your measurement needs.

Q: What benefits does the data logging feature provide for users?

A: The internal memory stores up to 47,000 data points, which lets users monitor sound over long periods without manual recording. This aids in comprehensive trend analysis and helps with regulatory documentation.
