HTC 5PSI Manometer, PM-6105

Name: HTC 5PSI Manometer, PM-6105
Brand: True Sense Technologies
Price: 2861.0 INR
Availability: InStock

Price 2861.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

HTC 5PSI Manometer, PM-6105 Specification

Sensor Type
Pressure Sensor

Humidity %
0 to 80% RH (non-condensing)

Protection
Over Range Protection

Temperature Range
0C to 50C

Application Media
Air, Non-corrosive Gases

Resolution
0.001 PSI

Equipment Type
Digital Manometer

Measurement Range
-5 PSI to +5 PSI

Pressure Range
-5 PSI ~ +5 PSI

Material
ABS Plastic Housing

Power Supply
9V Battery (included)

Power Consumption
Approx. 10mA

Accuracy
0.3% Full Scale

Display Type
Large LCD Display

Range
5 PSI

Zero Adjustment
Manual zero setting

Dimension
182 x 72 x 30 mm

Overload Indication
Display shows "OL"

Low Battery Indication
Yes

Data Hold Function
Yes

Sampling Rate
Approximately 0.5 seconds

Weight
Approximately 180 grams (without battery)

Backlight
Yes, LCD backlight for low-light visibility

HTC 5PSI Manometer, PM-6105 Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
2 Days

About HTC 5PSI Manometer, PM-6105

HTC PM-6105 Digital Manometer is a high-precision instrument designed for accurate pressure measurement up to 5 PSI. Its compact and portable design, combined with a backlit LCD, makes it suitable for professional and industrial applications.

Features:

High-precision pressure measurement up to 5 PSI
Multi-unit capability for versatile readings
Backlit LCD display for easy viewing
Compact and ergonomic design
Lightweight and portable
Fast and accurate response
Durable construction for industrial use
User-friendly interface
Suitable for HVAC, lab, and field applications
Monitors pressure-sensitive systems efficiently

Precision and Visibility Combined

The HTC 5PSI Manometer, PM-6105, stands out for its accurate pressure measurement and user-centric features such as a large backlit LCD display, manual zero adjustment, and data hold function. Whether you are working in demanding environments or low-light conditions, the device's thoughtful design makes readings easy and precise.

Built for Versatility and Durability

With a measurement range of -5 to +5 PSI, this manometer is suitable for diverse applications involving air and non-corrosive gases. The rugged ABS plastic housing protects the sensitive sensor, while the compact form ensures portability without compromising reliability or accuracy.

FAQ's of HTC 5PSI Manometer, PM-6105:

Q: How do I adjust the zero setting on the HTC 5PSI Manometer, PM-6105?

A: To perform a manual zero setting, ensure the device is powered on and exposed to atmospheric conditions with no pressure connections. Press and hold the zero adjustment button until the LCD reads zero, ensuring accurate baseline measurements.

Q: What types of media can I measure with this manometer?

A: This manometer is designed to measure air and other non-corrosive gases. It should not be used with corrosive substances or liquids, as these can damage the internal pressure sensor.

Q: When should I replace the battery in my PM-6105 Manometer?

A: Replace the 9V battery when the low battery indicator appears on the display. Regularly monitoring battery status helps ensure uninterrupted operation and accurate readings.

Q: Where is this device typically used?

A: The HTC PM-6105 is widely utilized in industrial and laboratory settings, HVAC systems, field service work, and other professional environments across India where accurate low-pressure measurements are essential.

Q: What is the process for holding data on the screen?

A: While measuring, activate the data hold function by pressing the dedicated button. This will freeze the current value on the LCD, allowing you to record or review readings without losing data due to fluctuations.

Q: How does the overload protection feature benefit the user?

A: If the applied pressure exceeds the -5 to +5 PSI range, the display shows 'OL,' preventing sensor damage and inaccurate readings. This feature safeguards both the device and your valuable data.

Q: What are the primary benefits of using the PM-6105 for pressure measurement?

A: This digital manometer offers precise readings with high accuracy, quick sampling, backlight for low-light visibility, and user-friendly functions. Its portable design and robust construction make it ideal for various industrial applications requiring reliable air or gas pressure monitoring.
